The Antennae - FINAL RESULTS NOW UPLOADED

This is a DSLR "Work-in-Progress", and also an exercise in theory meets practice.

I have been experimenting with different ISO settings on my uncooled 400D in an attempt to find an optimum, and (being the nerdy type that I am) thought the best way to settle it would be to conduct an experiment. Firstly run a series of darks at different temps and plot SNR vs exposure time for different ISOs and temperatures (as per Roger Clark's methods here). Graphs are relative to the noise of my 400D at 300s ISO800 and 20 degrees C (the plot for 20C is not shown here)

To my surprise ISO1600 came up trumps, so it was time to test with something challenging. I decided NGC4038 - The Antennae.

The data I have so far was taken over two nights using my VC200L with focal reducer - this is a HDR combine in Pixinsight of 67 x 180s ISO1600 subs (ambient temps of about 10-14C) and 53 x 240s ISO1600 subs (ambient temps of about 8-13C). Hi res version here: http://www.astrobin.com/full/40743/?mod=none

Am hoping to add to this over the next few imaging sessions, but I thought the process of determining exposure time might be of interest to some. And of course any advice or comments on my image capture and processing is also very welcome. The balance between the background and extended galaxy arms in particular I found quite challenging. I plan to post some updated images when I have collected some more data.

Thanks for looking
Attached Thumbnails
Click for full-size image (NGC4038 day 1 and 2 crop sm.jpg)
44.2 KB257 views
Click for full-size image (NGC4038 day 1 and 2.jpg)
111.3 KB176 views
Click for full-size image (SNR 14C.png)
22.5 KB155 views
Click for full-size image (SNR 3C.png)
20.5 KB131 views

Last edited by rmuhlack; 05-05-2013 at 07:31 PM. Reason: astrobin link
Reply With Quote
  #2
Old 03-05-2013, 11:57 AM
gregbradley's Avatar
gregbradley
Registered User

gregbradley is offline

Join Date: Feb 2006
Location: Sydney
Posts: 16,350
Great image Richard. Way better than I would normally expect to see from a DSLR.

So you took various images at various image lengths and plotted the resulting SNR (measured at the same spot on each image?).

I wonder if this result would vary with ambient temperature as sensor noise varies with temp.

Great work. I'll have to do the same with my Nikon D800e to see what the ideal ISO is for it.

Greg.
Reply With Quote
  #3
Old 03-05-2013, 11:57 AM
tilbrook@rbe.ne's Avatar
tilbrook@rbe.ne (Justin Tilbrook)
JHT

tilbrook@rbe.ne is offline

Join Date: Jun 2007
Location: Penwortham
Posts: 3,039
That's impressive Richard!

I tried the Antennae last year, got nothing like your image.
you've inspired me to try again.

Cheers,

Justin.
Reply With Quote
  #4
Old 03-05-2013, 12:07 PM
rmuhlack's Avatar
rmuhlack (Richard)
Professional Nerd

rmuhlack is offline

Join Date: Nov 2011
Location: Strathalbyn, SA
Posts: 873
Thanks Greg/Justin.

Greg - it does vary with temp as you would expect. The graphs show the SNR for two data sets - one for an ambient of 14C (this was basically constant throughout this test) and then another where ambient varied from 5.5 down to 3 C during the test (and this variation should be taken into account when interpreting the results. ideally I should do it again when temps are expected to be more constant). Its done by taking a series of dark frames only, and then measuring the standard deviation of each dark frame (across the entire frame). Roger Clark's website gives the formulae for then calculating relative SNR.
Reply With Quote
  #5
Old 03-05-2013, 12:14 PM
rmuhlack's Avatar
rmuhlack (Richard)
Professional Nerd

rmuhlack is offline

Join Date: Nov 2011
Location: Strathalbyn, SA
Posts: 873
One clear insight from those plots is that my earlier idea of using ISO400 which has a lower gain and therefore greater dynamic range wasn't doing me any favours with respect to noise (even though I did see much better star colour). eg this image of Corona Australis from two weeks ago: http://www.iceinspace.com.au/forum/a...e.php?a=137559

I think these results suggest that a better approach for me to enhance star colour would be to take a separate set of short subs at ISO1600 (say 60s) and then do a HDR combine in Pixinsight.
Reply With Quote
  #6
Old 03-05-2013, 12:35 PM
graham.hobart's Avatar
graham.hobart (Graham stevens)
DeepSkySlacker

graham.hobart is offline

Join Date: Nov 2008
Location: hobart, tasmania
Posts: 2,109
antennae

That's pretty cool Richard.
What do you think about a cooled DSLR?
If this keeps temp relatively constant (my CentralDS modded Canon will stay at 1'c EXIF) then shoot at 1600 but also with some shorter subs for the star colour?
Great thinking!
I like the cut of your jib my man!
PS Antennae are excellent
Keep up the good work
Graham.
Reply With Quote
  #7
Old 03-05-2013, 12:42 PM
rmuhlack's Avatar
rmuhlack (Richard)
Professional Nerd

rmuhlack is offline

Join Date: Nov 2011
Location: Strathalbyn, SA
Posts: 873
Thanks Graham. By cooling the DSLR you're going to get a similar sort of boost to SNR (when compared with an uncooled equivalent). However unless you have a very old CentralDS camera (like a 350D) the ISO you should use may be different as your camera will have different gain settings as its 14bit instead of the 12bits that im using.

But yes, i would imagine the same principle would still apply: Determine what ISO maximises your SNR, and then vary the sub length and use HDR combine to increase the effective dynamic range of your image

ps as a side point, i'm curious to know what sort of condensation problems are seen with a cooled DSLR, when the cooling takes the camera below the ambient dew point..?
Reply With Quote
  #8
Old 03-05-2013, 02:16 PM
RickS's Avatar
RickS (Rick)
PI cult recruiter

RickS is offline

Join Date: Apr 2010
Location: Brisbane
Posts: 10,584
Very nice work, Richard! Some good research and a nice image.
Reply With Quote
  #9
Old 03-05-2013, 02:52 PM
Larryp's Avatar
Larryp (Laurie)
Registered User

Larryp is offline

Join Date: Apr 2012
Location: Sydney
Posts: 5,244
Very nice, Richard
Reply With Quote
  #10
Old 03-05-2013, 03:46 PM
multiweb's Avatar
multiweb (Marc)
ze frogginator

multiweb is offline

Join Date: Oct 2007
Location: Hinchinbrook
Posts: 19,689
Impressive. Great write up. Thanks for the links.
Reply With Quote
  #11
Old 04-05-2013, 08:37 AM
Ross G
Registered User

Ross G is offline

Join Date: Apr 2007
Location: Cherrybrook, NSW
Posts: 5,006
Great looking photo Richard.

When I was shooting with a Canon 350d and 1000d I also found that 1600asa seemed to be the "sweet" spot.

Good luck.

Ross.
Reply With Quote
  #12
Old 04-05-2013, 08:57 PM
David Fitz-Henr's Avatar
David Fitz-Henr
Registered User

David Fitz-Henr is offline

Join Date: Aug 2007
Location: Bowen Mountain
Posts: 828
Excellent image Richard!
Reply With Quote
  #13
Old 05-05-2013, 06:04 PM
rmuhlack's Avatar
rmuhlack (Richard)
Professional Nerd

rmuhlack is offline

Join Date: Nov 2011
Location: Strathalbyn, SA
Posts: 873
The final results

Well I now have almost twice the amount of image data on the Antennae that I did before. As far as a practical test of using ISO1600 to maximise SNR, I think the results here speak for themselves. I am very happy with this result

The final tally comes in at:

Day 1: 67 x 180s ISO1600 subs (ambient temps of about 10-14C)
Day 2: 53 x 240s ISO1600 subs (ambient temps of about 8-13C)
Day 3: 47 x 180s ISO1600 subs (ambient temps of about 10-13C)
Day 3 continued: 49 x 240s ISO1600 subs (ambient temps of about 7-10C)

I have uploaded a "widefield", a close-in crop, and just for laughs a comparison with Hubble's famous image of this galaxy pair

Processed with Pixinsight. Hi res image here: http://www.astrobin.com/full/40910/?mod=none

As always, feedback welcome
Attached Thumbnails
Click for full-size image (NGC4038 day 1 2 and 3 v1 sm.jpg)
62.6 KB77 views
Click for full-size image (NGC4038 day 1 2 and 3 v1 crop sm.jpg)
75.1 KB91 views
Click for full-size image (NGC4038 Hubble Comparison.jpg)
78.8 KB112 views

Last edited by rmuhlack; 05-05-2013 at 06:19 PM.
Reply With Quote
  #14
Old 05-05-2013, 06:41 PM
E_ri_k (Erik)
Registered User

E_ri_k is offline

Join Date: Jun 2011
Location: Lakes Entrance
Posts: 823
Thats impressive Richard! Well done
Erik
Reply With Quote
  #15
Old 05-05-2013, 07:41 PM
RickS's Avatar
RickS (Rick)
PI cult recruiter

RickS is offline

Join Date: Apr 2010
Location: Brisbane
Posts: 10,584
Lovely image, Richard!
Reply With Quote
  #16
Old 05-05-2013, 07:50 PM
LucasB (Lucas)
Registered User

LucasB is offline

Join Date: Jul 2011
Location: Melbourne
Posts: 349
Great stuff Richard. That is very impresive and I also love the experimenting and documented results.

Lucas
Reply With Quote
  #17
Old 05-05-2013, 08:06 PM
strongmanmike's Avatar
strongmanmike (Michael)
Woohoo it's clear

strongmanmike is offline

Join Date: May 2006
Location: Canberra
Posts: 15,223
The final result is excellent Richard, one to be proud of

and go the Hubble comparisons, never done it myself but looks like a good idea

Mike
Reply With Quote
  #18
Old 05-05-2013, 08:07 PM
rmuhlack's Avatar
rmuhlack (Richard)
Professional Nerd

rmuhlack is offline

Join Date: Nov 2011
Location: Strathalbyn, SA
Posts: 873
Quote:
Originally Posted by strongmanmike View Post
The final result is excellent Richard, one to be proud of

and go the Hubble comparisons, never done it myself but looks like a good idea

Mike
LOL thanks Mike (hmm...I wonder where I got the idea from...)
Reply With Quote
  #19
Old 05-05-2013, 08:20 PM
strongmanmike's Avatar
strongmanmike (Michael)
Woohoo it's clear

strongmanmike is offline

Join Date: May 2006
Location: Canberra
Posts: 15,223
Quote:
Originally Posted by rmuhlack View Post
LOL thanks Mike (hmm...I wonder where I got the idea from...)
Oh yeeeeahh...thoooose

Mike
Reply With Quote
  #20
Old 05-05-2013, 08:56 PM
Shiraz's Avatar
Shiraz (Ray)
Registered User

Shiraz is offline

Join Date: Apr 2010
Location: ardrossan south australia
Posts: 4,822
very impressive image Richard. Nice when an experimental investigation pays off. Regards Ray
