Saturn August 7th 2023

Imaged Saturn August 7th, have data covering 3 hr 1 min of Saturn rotation. Have good 685nm IR data, very good CH4 data, fair R data but poor G and B data so a rather ordinary RGB.
Note a particularly interesting feature consisting of a v-bright elongated spot just below the ring shadow with an accompanying bright linear feature just below it. I previously captured this structure in my July 24th data. All data has been uploaded to PVOL with links here to the animations.

Detail resolved in these data.

A v-bright elongated feature in the EZ at approx Lat+3.0 L1 206.6 resolved in IR data.
A bright elongated spot on the edge of the ring shadow at approx Lat-18.3 L1 192.2 resolved in IR data.
A bright elongated spot on the edge of the ring shadow at approx Lat-17.8 L1 291 resolved in IR and R data.
A v-bright extended linear feature centered on approx Lat-24.7 extending from L1 293.5 to L1 274 the best data resolves this into a v-close series of bright spots resolved in IR data.
A bright linear feature is seen mid SEB from limb to limb including a brighter section at approx Lat-31.6 L3 35.3 to L3 9.0 the best data resolves this into a v-close series of bright spots resolved in IR data.
A bright oval in the STrZ impinging up into the SEB at approx Lat-29.5 L3 310.4 resolved in R data.
The long lived red spot at approx Lat-55.6 L3 80.9 resolved in IR data.

http://pvol2.ehu.eus/pvolimages/satu...85nmIR_tba.gif

http://pvol2.ehu.eus/pvolimages/satu...5-03_r_tba.gif
Attached Thumbnails
Click for full-size image (s2023-08-07_13-45_ir_tba.png)
109.7 KB116 views
Click for full-size image (s2023-08-07_13-55-48_r_tba.png)
140.6 KB114 views
Click for full-size image (s2023-08-07_16-20_ir_tba.png)
111.3 KB110 views
Click for full-size image (s2023-08-07_16-30_CH4_tba.png)
130.8 KB108 views
Click for full-size image (s2023-08-07_16-46_ir_tba.png)
145.5 KB88 views
Reply With Quote
  #2
Old 14-08-2023, 11:24 PM
Dave882 (David)
Registered User

Dave882 is offline

Join Date: Nov 2020
Location: PADSTOW
Posts: 2,491
Incredible detail in those IR shots. Quite a range of features. Can I ask what program you use to pinpoint such precise coordinates for these features?
Reply With Quote
  #3
Old 17-08-2023, 11:44 AM
Averton (P and C)
Registered User

Averton is offline

Join Date: Mar 2019
Location: Melbourne
Posts: 1,668
Sensational captures Trevor!
Reply With Quote
  #4
Old 17-08-2023, 01:51 PM
Crater101's Avatar
Crater101 (Warren)
Mostly Harmless

Crater101 is offline

Join Date: Jul 2020
Location: Bathurst, NSW
Posts: 786
I don't know about an "ordinary" RGB, this is a fine representation of Saturn. Nice work, as always!
Reply With Quote
  #5
Old 18-08-2023, 06:31 PM
Quark's Avatar
Quark (Trevor)
Registered User

Quark is offline

Join Date: Apr 2008
Location: Broken Hill NSW Australia
Posts: 4,104
Quote:
Originally Posted by Dave882 View Post
Incredible detail in those IR shots. Quite a range of features. Can I ask what program you use to pinpoint such precise coordinates for these features?
Thanks very much Dave, I measure the co-ordinates in WinJUPOS. For best accuracy the outline needs to be very accurately positioned. I increase the gamma until the moons that are in the field become visible and adjust the outline until the moons coincide with there positions from the outline.
Reply With Quote
  #6
Old 18-08-2023, 06:33 PM
Quark's Avatar
Quark (Trevor)
Registered User

Quark is offline

Join Date: Apr 2008
Location: Broken Hill NSW Australia
Posts: 4,104
Thanks very much Clare & Peter and Warren.
