not all lost - m42 on a moonlit light polluted evening

took this on thursday night , with a stack of 19x10sec, 47x30sec, 14x300sec and 4x605sec exposures, through heavy light pollution with the dog track, neighbours and the moon. that CLS filter is worth its weight in gold - without it imaging would be near impossible. However the colour cast can be a hell of an issue. When i get some time i need to watch the tutorial by Louie on masking, but i fear because i didnt take 1 min or 2 min shots i am shot.....

its crud but at least i got something its only 2h17min worth.

cooled 40D on 127Ed on G11 inthe doghouse obsrevatory

stacked in DSS and processed in Pixinsight.

EDIT NEW improved version here
Attached Thumbnails
Click for full-size image (orionweb25112010.jpg)
195.1 KB144 views

Last edited by h0ughy; 02-12-2010 at 06:10 PM.
Reply With Quote
  #2
Old 26-11-2010, 11:46 PM
jenchris's Avatar
jenchris (Jennifer)
Registered User

jenchris is offline

Join Date: Nov 2010
Location: Ormeau Gold Coast
Posts: 2,067
Bloody Brill!
Reply With Quote
  #3
Old 27-11-2010, 12:08 AM
dugnsuz's Avatar
dugnsuz (Doug)
Registered User

dugnsuz is offline

Join Date: Aug 2005
Location: Hahndorf, South Australia
Posts: 4,373
Nice one Dave - lots of subtle detail in the low-res.
I've always found this simple tutorial a good one for sorting out core problems in M42...
http://www.astropix.com/PFA/SAMPLE4A/SAMPLE4A.HTM
Reply With Quote
  #4
Old 27-11-2010, 08:34 AM
multiweb's Avatar
multiweb (Marc)
ze frogginator

multiweb is offline

Join Date: Oct 2007
Location: Sydney
Posts: 22,079
Beautiful.
Reply With Quote
  #5
Old 27-11-2010, 09:17 AM
h0ughy's Avatar
h0ughy (David)
Moderator

h0ughy is offline

Join Date: Apr 2005
Location: NEWCASTLE NSW Australia
Posts: 33,425
Quote:
Originally Posted by jenchris View Post
Bloody Brill!
thanks

Quote:
Originally Posted by dugnsuz View Post
Nice one Dave - lots of subtle detail in the low-res.
I've always found this simple tutorial a good one for sorting out core problems in M42...
http://www.astropix.com/PFA/SAMPLE4A/SAMPLE4A.HTM
yeah thats the other one ta

Quote:
Originally Posted by multiweb View Post
Beautiful.
far too kind with that response Marc
Reply With Quote
  #6
Old 27-11-2010, 09:37 AM
irwjager's Avatar
irwjager (Ivo)
Registered User

irwjager is offline

Join Date: Apr 2010
Location: Melbourne
Posts: 532
I'd be pretty darn happy with that!
Personally, when it comes to the Great Orion Nebula, I don't mind a slightly blown out core - it makes it look a bit more 3D and I find my brain actually fills in the core for me. But that's probably because I've been staring at that sucker way too much
Quote:
Originally Posted by h0ughy View Post
took this on thursday night , with a stack of 19x10sec, 47x30sec, 14x300sec and 4x605sec exposures
Quote:
but i fear because i didnt take 1 min or 2 min shots i am shot.....
You got a nice mix of exposures there, so creating a 60sec-120sec approximation from those shouldn't be too much of a problem? (bump the levels in the 30sec stack by 2x?)
Reply With Quote
  #7
Old 27-11-2010, 11:37 AM
CoolhandJo's Avatar
CoolhandJo (Paul)
Registered User

CoolhandJo is offline

Join Date: Oct 2008
Location: Sydney
Posts: 1,809
Very nice colours and detail regardless of colour cast.
Reply With Quote
  #8
Old 27-11-2010, 12:17 PM
strongmanmike's Avatar
strongmanmike (Michael)
Highest Observatory in Oz

strongmanmike is offline

Join Date: May 2006
Location: Canberra
Posts: 17,681
Hey we must have been imaging at the same time

This is pretty alright Dave, sure no Gendler show stopper but I like it and you should be very happy that this sort of image is possible from Walsend with dog tracks and suburban light pollution hanging like a shade cloth gazebo overhead

Mike
Reply With Quote
  #9
Old 27-11-2010, 02:08 PM
h0ughy's Avatar
h0ughy (David)
Moderator

h0ughy is offline

Join Date: Apr 2005
Location: NEWCASTLE NSW Australia
Posts: 33,425
Quote:
Originally Posted by strongmanmike View Post
Hey we must have been imaging at the same time

This is pretty alright Dave, sure no Gendler show stopper but I like it and you should be very happy that this sort of image is possible from Walsend with dog tracks and suburban light pollution hanging like a shade cloth gazebo overhead

Mike
the irony is i didnt use DBE (dynamic background extraction) to removethe light gradient as it was swimming up out of the mud into the murk.... might be another repro......
Reply With Quote
  #10
Old 27-11-2010, 02:14 PM
Sylvain (Jon)
Stars Chaser

Sylvain is offline

Join Date: Oct 2008
Location: Sydney
Posts: 294
wow super nice! congrats!
Reply With Quote
  #11
Old 27-11-2010, 04:58 PM
Hagar (Doug)
Registered User

Hagar is offline

Join Date: Oct 2006
Location: Australia
Posts: 4,646
Very nice result David, Smoooth as silk, but you needed those short exposures for the core. It would have been a real ripper with the core masked.
Reply With Quote
  #12
Old 27-11-2010, 06:19 PM
h0ughy's Avatar
h0ughy (David)
Moderator

h0ughy is offline

Join Date: Apr 2005
Location: NEWCASTLE NSW Australia
Posts: 33,425
Quote:
Originally Posted by Sylvain View Post
wow super nice! congrats!
thanks

Quote:
Originally Posted by Hagar View Post
Very nice result David, Smoooth as silk, but you needed those short exposures for the core. It would have been a real ripper with the core masked.
yes it would have improved it - i got photon fever and rushed it - there was only a limited amount of time to do it and i rushed it. the imaging session was not planned at all - just happened . i hope to have another go next week (if it ever clears). i have not shifted the camera so i hope to get it close to the same position as this one and redo some more data

I hope to use this method on the image next time http://pixinsight.com/forum/index.php?topic=2320.0
Reply With Quote
  #13
Old 28-11-2010, 12:39 AM
h0ughy's Avatar
h0ughy (David)
Moderator

h0ughy is offline

Join Date: Apr 2005
Location: NEWCASTLE NSW Australia
Posts: 33,425
goodness me i have committed photon murder

i tried the hdr method in pixinsight - just ran the script no tweaking of it. i need lots more data and lots more practice LOL. For those with a delicate palate please look away. its a horrible mess and i have lots of issues

repro.....coming up sorry i had to post the train wreck
Attached Thumbnails
Click for full-size image (HDR_DBEweb.jpg)
199.9 KB41 views
Reply With Quote
  #14
Old 28-11-2010, 09:33 AM
marc4darkskies's Avatar
marc4darkskies (Marcus)
Billions and Billions ...

marc4darkskies is offline

Join Date: Mar 2007
Location: Quialigo, NSW
Posts: 3,143
Ahh Dave, you're always so hard on yourself! Perfectly respectable image IMO. Why don't you layer the less burnt out core of the repro into the original version? Maybe tweak the colour balance for a bit more of a pinkish hue (looks a bit orange to me) and you'll be laughing!

Cheers, Marcus
Reply With Quote
  #15
Old 01-12-2010, 08:12 AM
h0ughy's Avatar
h0ughy (David)
Moderator

h0ughy is offline

Join Date: Apr 2005
Location: NEWCASTLE NSW Australia
Posts: 33,425
last thursday Al Meehan and I imaged the same area of sky, whilest the orientation of the camera was not the same he got a heap of deep 10min shots and i got a mixed bag of shots , well when they are all combined in DSS and stacked this is the RAW result not stretched or level adjusted (saved from tiff to jpeg for display ) collaberation!!!??? yes its worth it! total stacked image time is 5h 7min plus a few seconds. Both have cooled 40D's, both use CLS filter, note the image is not been processed yet
Attached Thumbnails
Click for full-size image (oroinstackall5h7minunprocessed.jpg)
179.7 KB46 views
Reply With Quote
  #16
Old 01-12-2010, 01:06 PM
alan meehan's Avatar
alan meehan (Alan)
Registered User

alan meehan is offline

Join Date: Jul 2005
Location: maryland newcastle AUSTRALIA
Posts: 1,851
This could be BIG
Reply With Quote
  #17
Old 01-12-2010, 11:26 PM
h0ughy's Avatar
h0ughy (David)
Moderator

h0ughy is offline

Join Date: Apr 2005
Location: NEWCASTLE NSW Australia
Posts: 33,425
dont know about BiG, Al, but it is certainly different for me. it is the first ever shot were i have not killed the core - processed it in Pixinsight without having to resort to the masking technique used in photoshop.
Attached Thumbnails
Click for full-size image (oroinstackall5h7min_DBE_TOTALLYPROCESSEDINPIXINSIGHTweb.jpg)
196.5 KB31 views
Reply With Quote
  #18
Old 01-12-2010, 11:51 PM
h0ughy's Avatar
h0ughy (David)
Moderator

h0ughy is offline

Join Date: Apr 2005
Location: NEWCASTLE NSW Australia
Posts: 33,425
well i tried to subtly layer this into the original posted image to keep it looking "natural" LOL
Attached Thumbnails
Click for full-size image (orion3layeropacityweb.jpg)
195.2 KB58 views
Reply With Quote
  #19
Old 02-12-2010, 09:26 AM
irwjager's Avatar
irwjager (Ivo)
Registered User

irwjager is offline

Join Date: Apr 2010
Location: Melbourne
Posts: 532
Quote:
Originally Posted by h0ughy View Post
well i tried to subtly layer this into the original posted image to keep it looking "natural" LOL
Spot on!
Reply With Quote
  #20
Old 02-12-2010, 12:27 PM
h0ughy's Avatar
h0ughy (David)
Moderator

h0ughy is offline

Join Date: Apr 2005
Location: NEWCASTLE NSW Australia
Posts: 33,425
thanks Ivo
Reply With Quote
